AI6C/AI-6C Fiber Optical Fusion Splicer- FO Splicer

Applicable Fibers     : SM(G.652&G.657) MM(G.651) DS(G.657) NZDSG.655
Splice Loss         : 0.025dB(SM) 0.01dB(MM)0.04dB(DS/NZDS)
Focus mode         : 6 motors Auto focus
Fiber alignment     : Core/cladding alignment Manual alignment
Typical splicing time     : 8S
Typical heating time     : 18S Fast heating function, heating time can be set Automatic heating(Preheating),heating programs(max.10)
Control technology     : Real-time control and calibration of fusion ARC
Return loss         : Better than 60DB
Fiber diameter         : Cladding Diameter 80-150m, Coating Diameter 100-1000m
Fiber Cleave Length     : Coating less than 250m5-16mm Coating less m250-1000m:16mm
Shrinkable tube     : 60mm/50mm/40mm/25mm
Boot time         : 1 second
Tension Test         : Standard 2N
Fiber holders         : 3 in 1 fiber holderSM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable
Magnification         : 300 for X or Y , 150 for XY view
Screen             : 5 inch TFT color display
Software update length     : Automatically update, Update by a key
Splicing Mode         : Normal / high precision splicing(splicing prograns max 100)
Splicing method     : Fully automatic,step by step splicing
Splicing record storage : Synchronize to the phone, the server to cloud storage unlimited
Built-in battery     : 5200 mAh high-capacity lithium battery, charging time3.5 hours, continuous splicing and heating about 160 times
Power supply         : Input AC100-240V 50 / 60HZ, output DC13.5V / 4.8A, the current power mode can be identified, real-time detection of battery power
Conditions         : Temperature -15 ~ +50 , humidity: <95% RH (no condensation),Working altitude: 0 5000m. Resist max. wind speed: 15m / s
Product protection     : Waterproof IP 22,dust proof IP54,shock-resistant
Language setting     : 10 languages to switch freely
